HYT-series 6 colour high speed Flexographic Printing Machine

 0086-577-58910222

Inquiry Download PDF

DESCRIPTION

1. Low speed and full load startup; stable running by tension control when increasing and decreasing speed , noise is decreased

2. High dots presentation rate under high speed; clear and vivid stratification of screen printing; strong stereo effect and accurate registering.

3. Aluminum roller adopts the Japan semi-sealing small bearing; flinty oxidation, static and dynamic balancing treatments are conducted; low resistance and small flop.

4. The special made modulus angular gears adopted; accurate printing size and full printing specifications (5mm is a spec)

5. With the air exhaust, blowing and heating settings; the heating system adopts the central thermostatic control system and group management, also with the cold air forming devices.

6. Printing rolls should keep moving while machine halted

7. Material holder use air shaft

8. Autotension control

9. Unwind with auto deviation correction system (EPC)

10. EDGE position control

11. Reversible printing 6 color press for6+0, 1+5, 2+4, 3+3.

12. 1 sets of printing cylinder, sizes: 15 inches.

Printing width	600mm - 1600mm
Printing material	PVC:35~70μm,OPP:20~70μm,BOPP:18~60μm,PE:35~100μm,
Printing material	NY:20~50μm,PET:12~60μm,CPP:20~60μm,p Paper:20~150g/m2
Printing color	at your own choice+ 2 special color
Printing length	7.5"～40"(190mm~1000mm)/7.5"～50"(190mm～1270mm)
Printing plate lifting system	Pneumatic press control
Machanical speed	100m/min
Printing speed	10～80m/min
Register precision	Longitude:±0.15mm Transverse:±0.15mm
Rewinder/Unwinder DIA	Φ1200mm

<td width="124

Inquiry

If you have any enquiry about quotation or cooperation,please feel free to email us at ray@sanbi.comor use the following enquiry form. Our sales representative will contact you soon. Thank you for your interest in our products.

* Title:

* Name:

* Tel:

* E-mail:

* Country:

* Content:

Related Products

Double-color Flexography Printing Machine

CI Central Drum Type Flexographic Printing Machine

Model SWZS Series Decorate Paper Printing And Coating Machine

Flexo Printing Machine, Four-Colour Flexographic Printing Machine

       


Printing width	600mm	800mm	1000mm	1200mm	1400mm	1600mm
Material feeding width	700mm	900mm	1100mm	1300mm	1500mm	1700mm
Master motor	3.7Kw	3.7Kw	3.7Kw	5.5Kw	5.5Kw	5.5Kw
Rewinder motor	1.5Kw	1.5Kw	1.5Kw	2.2Kw
